Features:
1. Combined with the characteristics of lead-acid battery and super capacitor, lead carbon battery has better comprehensive performance.
2. Excellent recharge acceptance and super fast charge discharge performance
3. Excellent PSoC and cyclic performance
4. Extreme temperature tolerance
5. High purity raw material: low self discharge rate.
6. Oxygen recombination technology: safe and eco-friendly.
Applications:
Solar energy system
Aerial Work Platform / Access
Floor cleaning machine
Recreational vehicles, marine
Specification:
Model | Norminal Voltage（V） | Capacity (Ah) | Dimension (mm) | Weight (kg±3%) | Terminal | Terminal Position | Screw | |||
L | W | H | Total H | |||||||
6 | 200/20HR | 306 | 168 | 220 | 226 | 31.0 | T5 | F | M8×18 | |
6 | 205/20HR | 260 | 180 | 246 | 252 | 30 | T5 | F | M8×18 | |
6 | 225/20HR | 243 | 187 | 275 | 275 | 32.5 | T5 | F | M8×18 | |
6 | 230/20HR | 260 | 180 | 265 | 272 | 34.2 | T5 | F | M8×18 | |
6 | 280/20HR | 295 | 178 | 346 | 350 | 45.8 | T5 | F | M8×18 | |
6 | 300/20HR | 295 | 178 | 346 | 350 | 46.5 | T5 | F | M8×18 | |
FCC6-340AT | 6 | 340/20HR | 295 | 178 | 404 | 408 | 55.0 | T5 | F | M8×18 |
FCC6-380AT | 6 | 380/20HR | 295 | 178 | 404 | 408 | 57.2 | T5 | F | M8×18 |
FCC12-20AT | 12 | 20/20HR | 166 | 175 | 126 | 126 | 8.4 | T2 | B | M6×16 |
FCC12-24AT | 12 | 24/20HR | 165 | 126 | 174 | 174 | 8.6 | T2 | B | M6×16 |
FCC12-30AT | 12 | 30/20HR | 196 | 130 | 155 | 167 | 10.2 | T3 | A | M6×16 |
FCC12-35AT | 12 | 35/20HR | 198 | 166 | 174 | 174 | 14 | T2 | B | M6×16 |
FCC12-50AT | 12 | 50/20HR | 229 | 138 | 208 | 212 | 17.7 | T3 | A | M6×16 |
FCC12-60AT | 12 | 60/20HR | 350 | 167 | 178 | 178 | 23 | T3 | B | M6×16 |
FCC12-75AT | 12 | 75/20HR | 260 | 169 | 211 | 215 | 26.0 | T3 | A | M6×16 |
FCC12-90AT | 12 | 90/20HR | 307 | 169 | 211 | 215 | 30 | T3 | A | M6×16 |
FCC12-100AT | 12 | 100/20HR | 328 | 172 | 218 | 222 | 33.0 | T4 | A | M8×18 |
FCC12-110AT | 12 | 110/20HR | 407 | 174 | 208 | 233 | 39 | T5 | A | M8×18 |
FCC12-120AT | 12 | 120/20HR | 341 | 173 | 283 | 287 | 40.5 | T5 | A | M8×18 |
FCC12-135AT | 12 | 135/20HR | 484 | 171 | 241 | 241 | 45.5 | T4 | A | M8×18 |
FCC12-180AT | 12 | 180/20HR | 532 | 206 | 215 | 219 | 58.5 | T4 | C | M8×18 |
FCC12-200AT | 12 | 200/20HR | 522 | 240 | 219 | 223 | 64.8 | T5 | C | M8×18 |
FCC12-220AT | 12 | 220/20HR | 520 | 268 | 203 | 207 | 70.8 | T5 | C | M8×18 |
FCC12-240AT | 12 | 240/20HR | 520 | 268 | 220 | 224 | 77.5 | T5 | C | M8×18 |
All data and specifications are subjected to change without notice, please contact MCA to confirm information. | ||||||||||
